mac m1에서 vagrant를 이용해 쿠버네티스 실습환경 구축(기본 환경)

0. vmware install



1. vagrant down

$brew install vagrant



2. utility install

https://www.vagrantup.com/docs/providers/vmware/vagrant-vmware-utility

Vagrant by HashiCorp



3. plugin install

#vagrant plugin install vagrant-vmware-desktop

https://www.vagrantup.com/docs/providers/vmware/installation

Vagrant by HashiCorp



end.

#vagrant up



---

(timeout error 해결)



vagrant up

해당 명령을 실행했을 때 timeout error 발생

boot_timeout을 늘려주면 됩니다.



저는 아래와 같이 설정했습니다.

# -*- mode: ruby -*-
# vi: set ft=ruby :
Vagrant.configure("2") do |config|
  N = 3 #max number of worker nodes
  Ver = '1.18.3' #Kubernetes Version to install
  config.vm.define "m-k8s" do |cfg|
  config.vm.boot_timeout = 1800 #30minutes
    cfg.vm.box = "sysnet4admin/CentOS-k8s"
    cfg.vm.provider "virtualbox" do |vb|
      vb.name = "m-k8s(kimbg)"
      vb.cpus = 2
      vb.memory = 2048
      vb.gui = false
      vb.customize ["modifyvm", :id, "--groups", "/k8s-SM(kimbg)"]
    end #end |vb|
    cfg.vm.host_name = "m-k8s"
    cfg.vm.network "private_network", ip: "192.168.1.10"
    cfg.vm.network "forwarded_port", guest: 22, host: 60010, auto_correct: true, id: "ssh"
    cfg.vm.synced_folder "../data", "/vagrant", disabled: true
	cfg.vm.provision "shell", path: "config.sh", args: N
    cfg.vm.provision "shell", path: "install_pkg.sh", args: [ Ver, "Main" ]
	cfg.vm.provision "shell", path: "master_node.sh"

  end #end |cfg|

  (1..3).each do |i|
    config.vm.define "w#{i}-k8s" do |cfg| # #{i}에는 each문 1, 2, 3이 들어감
	config.vm.boot_timeout = 1800 #30minutes
		cfg.vm.box = "sysnet4admin/CentOS-k8s"
		cfg.vm.provider "virtualbox" do |vb|
		  vb.name = "w#{i}-k8s(kimbg)"
		  vb.cpus = 1
		  vb.memory = 1024
		  vb.gui = false
		  vb.customize ["modifyvm", :id, "--groups", "/k8s-SM(kimbg)"]
		end #end |vb|
		cfg.vm.host_name = "w#{i}-k8s"
		cfg.vm.network "private_network", ip: "192.168.1.10#{i}"
		cfg.vm.network "forwarded_port", guest: 22, host: "6010#{i}", auto_correct: true, id: "ssh"
		cfg.vm.synced_folder "../data", "/vagrant", disabled: true
        cfg.vm.provision "shell", path: "config.sh", args: N
		cfg.vm.provision "shell", path: "install_pkg.sh", args: Ver
		cfg.vm.provision "shell", path: "work_nodes.sh"
    end #end |cfg|
  end #end |i|
end #end |config|



해결
